SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 132KW FOR 150% 60S,100% 240S OUTPUT LIGHT OVERLOAD: 160KW FOR 110% 60S, 100% 240S AMBIENT TEMP 0 TO +40 DEG C 1447 X 452 X 328 (HXWXD), FSGX PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED with CU230P-2 FOR FIRMWARE-VERSION V4.6
Product | |||||||||||||||||||||||||||||||||||||
Article Number (Market Facing Number) | 6SL3310-1PE33-0AA0 | ||||||||||||||||||||||||||||||||||||
Product Description | SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 132KW FOR 150% 60S,100% 240S OUTPUT LIGHT OVERLOAD: 160KW FOR 110% 60S, 100% 240S AMBIENT TEMP 0 TO +40 DEG C 1447 X 452 X 328 (HXWXD), FSGX PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED with CU230P-2 FOR FIRMWARE-VERSION V4.6 | ||||||||||||||||||||||||||||||||||||
Product family | PM330 Power Modules | ||||||||||||||||||||||||||||||||||||
Product Lifecycle (PLM) | PM300:Active Product | ||||||||||||||||||||||||||||||||||||
Price data | |||||||||||||||||||||||||||||||||||||
Price Group / Headquarter Price Group | IE / 347 | ||||||||||||||||||||||||||||||||||||
List Price (w/o VAT) | Show prices | ||||||||||||||||||||||||||||||||||||
Customer Price | Show prices | ||||||||||||||||||||||||||||||||||||
Metal Factor | None | ||||||||||||||||||||||||||||||||||||
Delivery information | |||||||||||||||||||||||||||||||||||||
Export Control Regulations | AL : N / ECCN : EAR99H | ||||||||||||||||||||||||||||||||||||
Factory Production Time | 25 Day/Days | ||||||||||||||||||||||||||||||||||||
Net Weight (kg) | 98.000 Kg | ||||||||||||||||||||||||||||||||||||
Product Dimensions (W x L x H) | Not available | ||||||||||||||||||||||||||||||||||||
Packaging Dimension | 452.00 x 1447.00 x 328.00 | ||||||||||||||||||||||||||||||||||||
Package size unit of measure | MM | ||||||||||||||||||||||||||||||||||||
Quantity Unit | 1 Piece | ||||||||||||||||||||||||||||||||||||
Packaging Quantity | 1 | ||||||||||||||||||||||||||||||||||||
Additional Product Information | |||||||||||||||||||||||||||||||||||||
EAN | 4042948666579 | ||||||||||||||||||||||||||||||||||||
UPC | Not available | ||||||||||||||||||||||||||||||||||||
Commodity Code | 85044088 | ||||||||||||||||||||||||||||||||||||
LKZ_FDB/ CatalogID | D11.1SD | ||||||||||||||||||||||||||||||||||||
Product Group | 3502 | ||||||||||||||||||||||||||||||||||||
Group Code | R220 | ||||||||||||||||||||||||||||||||||||
Country of origin | Germany | ||||||||||||||||||||||||||||||||||||
Compliance with the substance restrictions according to RoHS directive | Since: 2009.02.18 | ||||||||||||||||||||||||||||||||||||
Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. | ||||||||||||||||||||||||||||||||||||
WEEE (2012/19/EU) Take-Back Obligation | – | ||||||||||||||||||||||||||||||||||||
REACH Art. 33 Duty to inform according to the current list of candidates |
|
||||||||||||||||||||||||||||||||||||
Classifications | |||||||||||||||||||||||||||||||||||||
|
