| Product | ||
| Article Number (Market Facing Number) | 6SL3210-1RH22-3AL0 | |
| Product Description | SINAMICS G120 POWER MODULE PM240P-2 WITH BUILT IN CL. A FILTER 3AC500-690V+10/-20% 47-63Hz OUTPUT HIGH OVERLOAD: 15KW FOR 150% 60S, 100% 240S; AMBIENT TEMP -20 TO +50 DEG C (HO) OUTPUT LOW OVERLOAD: 18.5kW FOR 135% 3S, 110% 57S, 100% 240S AMBIENT TEMP -20 TO +40 DEG C (LO) 472 X 200 X 237 (HXWXD), FSD PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.7 SP6 HF1 | |
| Delivery information | ||
| Export Control Regulations | ECCN : EAR99H / AL : N | |
| Factory Production Time | 10 Day/Days | |
| Net Weight (kg) | 18.900 Kg | |
| Packaging Dimension | 356.00 x 495.00 x 300.00 | |
| Package size unit of measure | MM | |
| Quantity Unit | 1 Piece | |
| Packaging Quantity | 1 | |
| Additional Product Information | ||
| EAN | 4042948673584 | |
| UPC | 804766459306 | |
| Commodity Code | 85044088 | |
| LKZ_FDB/ CatalogID | D11.1SD | |
| Product Group | 5678 | |
| Group Code | R220 | |
| Country of origin | Germany | |
| Compliance with the substance restrictions according to RoHS directive | Since: 2016.12.22 | |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
|
